Ring Making Machine R-6-300E

Get a Price/Quote

MOQ : 1 Piece

Ring Making Machine R-6-300E Specification

Shape
Round/Square ring

Phase
Three Phase

Torque
High torque driven

Diameter
6 mm - 30 mm

Product Type
Ring Making Machine

General Use
Wire bending, ring forming

Material
Mild Steel

Type
Fully Automatic

Capacity
Up to 5000 pieces/hr

Weight (kg)
800 kg

Computerized
Yes

Automatic
Yes

Touch Screen
Yes

Control System
PLC Control

Surface Treatment
Paint Coated

QC System
On-machine test facility & visual inspection

Tolerance
0.1 mm

Drawing
Available

Voltage
415 V

Dimension (L*W*H)
1800 x 1000 x 1700 mm

Feature
High speed, Easy operation, Precision ring forming

Color
Industrial Blue

Safety Features
Emergency Stop, Safety Guard, Overload protection

Speed
Up to 30 m/min

Wire Diameter Range
Up to 6 mm

Noise Level
Low (under 70 dB)

Operation Mode
Programmable for varied ring dimensions

Feeding System
Servo Controlled Roller Feed

Main Motor Power
3 HP

Lubrication
Automatic centralized lubrication system

Production Application
For manufacturing curtain rings, key rings, chain links, and related products

Bending Accuracy
High precision angle positioning system

About Ring Making Machine R-6-300E

Automatic Ring Making R-6-300 E Series

Automatic Ring Making and Welding Machine R-6-300 E Series

R-6-300E

Model: R-6-300 E-Series
Input voltage: 380V(3-phase) or custom
Power frequency: 50/60Hz
Instant power during welding: 15KVA(for 4mm wire)
Instant power during forming: 2KVA
Wire thickness: 2.8-5mm
Max ring diameter: 300mm
Min ring diameter: 70mm
Ring perimeter tolerance: 0.5mm

Features

R-6-300 E-Series is not equipped with digital regulation of ring sizes, the ranges of ring thickness and ring size are also less than R-6-300.

1. High precision: intelligent "S" shape speed curve, the encoder and the motor form a closed-loop wire feeding control system, secure a diameter tolerance less than 0.16mm, eventually solve the ring precision issues inherent in the traditional mechanical or hydraulic ring making machines.

Versatile Performance Across Applications

The R-6-300E excels in producing high-quality rings suitable for a range of uses, including curtain rings, key rings, and chain links. Its flexibility extends to both round and square ring styles, accommodating diameters from 6 mm to 30 mm. With programmable operation and on-machine testing, it easily adapts to complex production requirements, meeting the diverse needs of manufacturers, exporters, and suppliers alike.

Advanced Control and Safety Features

Equipped with a sophisticated PLC-based control system and touch screen interface, the R-6-300E offers intuitive operation and fast setup. Comprehensive safety features include emergency stop, safety guards, and overload protection, ensuring safe operation. The automatic centralized lubrication system further enhances reliability, reducing downtime and maintenance needs.

Precision Engineering for Quality Output

Delivering high bending accuracy with an advanced angle positioning system, the R-6-300E guarantees consistent results for every batch. The machines QC system consists of on-machine test facilities and visual inspection, ensuring each ring meets stringent quality standards. Coupled with high torque drive and low-noise operation, it supports efficient, quiet, and precise manufacturing environments.

FAQs of Ring Making Machine R-6-300E:

Q: How does the R-6-300E ensure high precision in ring forming?

A: The R-6-300E is equipped with a high precision angle positioning system and servo-controlled roller feed. This allows for consistent bending and forming of rings within a tight tolerance of 0.1 mm, regardless of wire material. The computerized PLC control and on-machine testing further ensure accurate ring dimensions for every production cycle.

Q: What types of rings and products can be manufactured with this machine?

A: This machine is designed for making curtain rings, key rings, chain links, as well as other similar products requiring precise wire bending. It supports both round and square ring shapes, with diameter capabilities ranging from 6 mm to 30 mm, making it versatile for a variety of industrial needs.

Q: When is the best situation to use the R-6-300E over manual ring forming?

A: The R-6-300E is ideal when high production volume, accuracy, and repeatability are required, such as in large-scale manufacturing environments or for consistent quality across batches. Its automated features and high capacity (up to 5000 pieces/hr) make it much more efficient than manual operations.

Q: Where is the R-6-300E commonly installed or used?

A: This machine is typically found in manufacturing facilities dedicated to hardware products, wire forming workshops, and factories producing rings for curtains, keys, and chains. Its robust design and comprehensive features suit uses by manufacturers, distributors, exporters, and suppliers.

Q: What benefits does the servo-controlled feeding system provide?

A: The servo-controlled roller feed ensures precise and repeatable wire advancement, which is crucial for maintaining the exact ring size and reducing material waste. It also enhances productivity and minimizes manual adjustments during production runs.

Q: How easy is it to operate and maintain the machine?

A: The R-6-300E offers user-friendly touch screen controls and fully automatic, programmable operation. Safety features like emergency stop and overload protection, along with automatic centralized lubrication, reduce maintenance frequency and ensure smooth, reliable operation.

Q: What is the process for changing ring dimensions or shapes during production?

A: Ring dimensions and shapes can be programmed directly through the touch screen interface, allowing for rapid changeovers between different production specifications. The machines PLC control system streamlines adjustments, enabling operators to switch between round and square rings with minimal downtime.
