Steel wire mesh welding machine

Model

GWC2800

Steel wire diameter

5-12mm

Max. mesh width/ cross wire length

2800mm

Meshs length

Any

Size of grid mesh

50-400mm adjustable

Line wire spacing

100-400mm (Multiple of 50)

Cross wire spacing

50-300mm, Step-less Adjustable

Max. welding capacity

12+12mm

Max. welding speed

~ 60 row/min

Max. welding spot nos.

28 Can be reduced

Wire feeding method (cross wire/line wire)

Pre-cut/off-coil

Material of steel wire

Cold rolled ribbed wire, Cold drawn wire, hot rolled ribbed wire (after straightened), Hot rolled plain wire, stainless steel wire, galvanized wire.

Voltage

380V / 50HZ,60HZ

Rated power

1400Kva (batch welding available, rated power will be lowered accordingly)

Air source supply

3 m/min

Air pressure

0.8Mpa

Cooling method

circulating water cooling

Reference dimension (L*W*H)

~30x5.5x2.5

Reference machines weight

14Ton
