Venturi Tube Welder

Get a Price/Quote

MOQ : 1 , , Piece

Venturi Tube Welder Specification

Welding
Tube Welding

Output Voltage
70 V

Diameter
25 mm to 100 mm

Application
Venturi Tube Fabrication & Welding

Power Consumption
5.2 kWh

Equipment Type
Industrial Welding Machine

Power Source
Electric

Frequency
50/60 Hz

Phase
Single/Three Phase

Type
Venturi Tube Welder

Condition
New

Motor Type
AC Motor

Material
Stainless Steel & Alloy

Power
5 kW

Voltage
220 V / 380 V

Dimensions
1350 mm x 600 mm x 1200 mm

Input Voltage
220 V

Rated Current
21 A

Rated Capacity
Max 80 kg/h

About Venturi Tube Welder

Venturi Tube Welder

Owing to the state-of-the-art facility and a dedicated workforce, we are able to manufacture, supply and export Venturi Tube Welder. Supreme quality raw materials and components have been procured from the trusted sources of the market for the manufacturing of these products. These products find application in industries that are involved in making welding bag cages of random lengths. Known for its longer service life, ability to bear adverse conditions, corrosion resistance, less wear & tear and sturdy construction, Venturi Tube Welder has gained a high demand in the global market.

Specifications:

Model: DW-80

Input voltage: 380V(2-phase) or specified by customer

Power freq.: 50Hz

Power capacity: 80KVA

Working load: 35KVA

Cooling: Water cooling

Water flow: 3L/min

Air flow: 80L/min

Air pressure: 0.6-0.8MPa

Insulation grade: F

Features

KD-D08B controller

Horizontal welding, applicable for welding bag cages of random lengths, supporting stand included

Filter Cages - round, star, oval, flat, peanut, spider and other odd shapes, with different connections, all can be customized.

Round cage size: OD100-200mm

Material: Mild steel wire, Stainless steel wire, Galvanized carbon steel wire, Titanium steel wire, etc.

Sizes of steel wire: 2.8-6mm

Advanced Tube Welding for Industrial Applications

Engineered for precision and efficiency, the Venturi Tube Welder addresses the needs of modern fabrication facilities. Its solid stainless steel and alloy build ensures durability, while flexible input voltages and a range of operating frequencies make it adaptable across various settings. The machines compact design and considerable capacity streamline the welding of venturi tubes, making it indispensable for manufacturers dealing in large-scale industrial projects.

Reliable and Efficient Design

With a 5 kW AC motor and power consumption of only 5.2 kWh, this welding machine is built for sustained industrial performance. Safety and productivity are amplified by its stable output voltage and rated current, ensuring even welds and consistent output quality. Its design supports easy operation in both single-phase and three-phase environments, broadening its applicability across diverse industrial standards.

FAQs of Venturi Tube Welder:

Q: How does the Venturi Tube Welder operate for tube fabrication?

A: The Venturi Tube Welder utilizes electric power to heat and fuse stainless steel or alloy tubes. The process involves precise control of voltage, current, and temperature to ensure uniform welds. Its AC motor drives the welding mechanism, effectively joining tubes ranging from 25 mm to 100 mm in diameter.

Q: What materials can be welded with this machine?

A: This welder is engineered to work with both stainless steel and alloy tubes, making it ideal for manufacturing venturi tubes that demand corrosion resistance and structural integrity.

Q: When should this equipment be used in the production process?

A: The Venturi Tube Welder is best utilized during the fabrication phase when raw tube sections require precision joining. It is suitable for both initial assembly and repair welds in venturi tube production.

Q: Where is the Venturi Tube Welder typically installed or used?

A: Due to its industrial design and capacity, the machine is commonly installed in fabrication workshops, manufacturing plants, and industrial facilities focused on tube processing and assembly.

Q: What is the welding process employed by this machine?

A: The welder uses electric tube welding, where controlled heat generated by a 5 kW AC motor fuses tube joints. Adjustments for output voltage and current allow operators to achieve optimal weld quality according to material thickness and tube diameter.

Q: How can users benefit from using this venturi tube welding machine?

A: Operators benefit from faster production rates, reliable weld consistency, and the versatility to work with a range of tube sizes and materials. Its robust construction ensures a long operational life with minimal maintenance, reducing downtime and costs.

Q: What kind of power sources are compatible with the machine?

A: The Venturi Tube Welder supports both 220 V and 380 V inputs at either 50 or 60 Hz, functioning in single-phase or three-phase configurations, making it suitable for worldwide industrial standards.
