Steel Wire Decoiler Machine

Get a Price/Quote

MOQ : 1 , , Piece

Steel Wire Decoiler Machine Specification

Power Source
Electric

Frequency
50 Hz

Application
Unwinding Steel Wire Coils

Diameter
Max. 900 mm

Power Consumption
2 kW

Phase
Three Phase

Automation Grade
Semi Automatic

Output Voltage
380 V

Equipment Type
Wire Decoiling Machine

Type
Steel Wire Decoiler Machine

Condition
New

Motor Type
AC Motor

Material
Mild Steel

Power
2 kW

Voltage
380 V

Dimensions
1200 mm x 900 mm x 1100 mm

Input Voltage
380 V

Rated Current
5.5 A

Rated Capacity
1500 kg

Mobility
Fixed / Stationary

Max Coil Weight
1500 kg

Maintenance
Low Maintenance Design

Coil Outer Diameter Range
Up to 900 mm

Safety Features
Emergency Stop Button

Coil Inner Diameter Range
450 mm to 650 mm

Mounting
Floor Mounted

Base Type
Heavy Duty Fabricated Base

Number of Spindles
Single Spindle

Surface Finish
Powder Coated

Noise Level
Low Noise Operation

Control Panel
Digital Control Panel

Speed Adjustment
Variable Speed Drive

About Steel Wire Decoiler Machine

Steel Wire Decoiler Machine

It is used for ring making machine & wire straightening machine, the steel wire decoiler automatically.

ZGTEK is recognized as the only company in the world expert in filter cage welding technologies and in China it is the only company capable of supplying high quality automatic ring making machines. ZGTEK has just started to develop wire mesh welding machines by cooperating with some mesh machine design experts.

Jiaxing Zhe Gong CNC Welding Machine Co., Ltd. (ZGTEK Co., Ltd) is located in Jiaxing City, Zhejiang Province (nearby Shanghai city), it's a partly state owned enterprise. The company possesses rich experience in resistance welding as well as automation, all based on its accumulated knowledge in wire welding.

Main Products

Filter cage welding machine lines
Ring making machines

Round ring making machine (RM series)
Oval ring making machine (OR series)
Automatic ring making and welding machine (R series)

Wire mesh welding machines

Automatic wire mesh making machine (GWC series)
CNC Reinforcement wire mesh welding machine

A basic Filter cage welding line consists of:

16 or 24-vertical wires cage body welding machine DLN-24/DLN-16,
Wire straightening machine TZ2.8-5
Ring making machine R-6-300/ RM-6-310
MS ring butt welding machine UR-40,
SS ring Argon Arc (TIG) welder ARW,
Top collar welder DS-80/D4S-80-2,
Bottom cap welder DX-80,
Venturi tube welder DW-80.

Filter Cages - round, star, oval, flat, peanut, spider and other odd shapes, with different connections, all can be customized.

Round cage size: OD100-200mm

Material: Mild steel wire, Stainless steel wire, Galvanized carbon steel wire, Titanium steel wire, etc.

Sizes of steel wire: 2.8-6mm

Innovative Design for Seamless Operation

Engineered with a heavy-duty fabricated base and powder-coated finish, the Steel Wire Decoiler Machine provides reliable stability and durability for continuous industrial use. Its single spindle mechanism accommodates coils with an inner diameter range of 450 mm to 650 mm and an outer diameter up to 900 mm, ensuring versatility for various wire sizes.

Enhanced Control and Safety Features

Equipped with a user-friendly digital control panel and precise variable speed drive, operators can effortlessly adjust the unwinding speed to match specific production requirements. An emergency stop button guarantees quick response during unexpected situations, while the low-noise, low-maintenance design facilitates safer and more comfortable working conditions.

FAQs of Steel Wire Decoiler Machine:

Q: How does the Steel Wire Decoiler Machine operate during wire coil unwinding?

A: The machine utilizes a single spindle to securely hold the steel wire coil. Powered by an AC motor with variable speed drive, it unwinds the coil smoothly, which can be precisely controlled through the digital control panel according to required process speeds.

Q: What types and sizes of steel wire coils are suitable for use with this decoiler machine?

A: It accommodates steel wire coils with inner diameters ranging from 450 mm to 650 mm and outer diameters up to 900 mm, with a maximum coil weight capacity of 1500 kg. This makes it ideal for a wide range of wire sizes in industrial applications.

Q: When should maintenance be performed on the steel wire decoiler machine?

A: Maintenance frequency depends on usage, but the machines low maintenance design means routine checks on mechanical parts and periodic cleaning are sufficient to ensure optimal performance and longevity.

Q: Where is the Steel Wire Decoiler Machine best installed for maximum stability and efficiency?

A: The unit is designed for fixed, floor-mounted installation on level industrial floors. Its heavy-duty fabricated base provides enhanced stability during operation, minimizing movement and vibration.

Q: What safety features are integrated into the decoiler machine?

A: A prominent emergency stop button is provided for immediate machine halt. Additionally, the low noise operation and powder-coated protective finish promote a safer and more comfortable working environment.

Q: How does variable speed adjustment improve the wire decoiling process?

A: Variable speed drive allows operators to control the unwinding speed, ensuring gentle handling of delicate wires and efficient processing of heavier coils, which enhances productivity and reduces material damage.

Q: What are the benefits of using the Steel Wire Decoiler Machine for manufacturers and suppliers?

A: Manufacturers and suppliers benefit from enhanced operational efficiency, consistent unwinding quality, low maintenance requirements, and improved safety features, making daily wire handling tasks more streamlined and cost-effective.
